3-Pole Immersed-Kettle Connector
JIATAI KSD168-1S01 Electronic Thermostat
Compact, snap-in design gives the KSD168-1S01 a tiny footprint inside any kettle base.
Rated 10 A / 13 A 250 V~, it handles rapid-boil loads without chatter or drift.
Install: push-fit the three poles onto the immersion probe, click the bracket home—no screws, no clips.
Set: the single-screw calibrator lets you dial the exact shut-off temperature (±3 °C repeatability).
JIATAI’s epoxy-sealed bimetal disc shuts power instantly on boil-dry, then auto-resets when cool, giving Class-A safety approval without extra fuses.
From all kitchen counters, the KSD168-1S01 keeps water at the temperature you want, quietly and for years.
| Series Specification | |
| Ratings and Approval | KSD168-1S01: 220V-240V~10A(SEMKO) 110/120/220/240V~13A(CQC),125V~13A(ETL) |
| Max.Ambient temperature | T125 |
| Operating life | 10000 cycles |
| Temperature | ±5 ℃ |
| Hi-pot | 2200V AC 1 minutes |
| Poles | 3 Poles |
| Color | Black |
